Annke H.265 Pro 8K 4CH NVR 8MP Poe Camera CCTV System 2.8mm Lens Human Vehicle Detection Video Surveillance Camera Protection

DVR

Video & Audio

Video Compression

H.264+/H.264/H.265/H.265+

Video Input

4CH Analog Camera+ 2CH IP Camera

Video Output

CVBS; VGA up to 1080p; HDMI up to 2K

Audio Input

4-ch via coaxial cable, 1CH RCA

Audio Output

1CH RCA

Supported Analog Camera Types

Support HD TVI Input:8 MP@15 fps, 5 MP@20 fps, 3K@20fps, 4 MP@30 fps, 4MP@25 fps, 3MP@18 fps, 1080p30, 1080p@25fps, 720p@60 fps, 720p@50 fps,
720p@30 fps, 720p@25 fps
Support AHD Input: 5 MP@20 fps, 4 MP@25 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
Support CVI Input: 5 MP@20 fps , 4 MP@25 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps
Support CVBS Input

Encoding resolution

Main stream: 8 MP@8 fps/5 MP@12 fps/3K@12fps/4 MP@15 fps/8 MP Lite@15fps/3 MP@18 fps1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30 fps (N)
*: 8 MP@8 fps is only available for channel 1, 8 MP Lite is only available
for channel 2 to channel 4
Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N)

Video bitrate

32 Kbps to 10 Mbps

Stream type

Video, Video & Audio

Audio compression

G.711u

Audio bitrate

64 Kbps

IP Camera Input

2-ch (up to 6-ch)

IPC Recording Resolution

Up to 8MP

IPC Playback Resolution

Up to 8MP

Max Playback Channel

4CH

Human/Vehicle Analysis

Up to 4-ch

ONVIF

Support

Hard Drive

HDD

1 SATA Interface

HDD Capacity

Up to 10 TB Capacity

External Interface

Network Interface

1, RJ45 10/100 Mbps self-adaptive Ethernet interface

USB

USB 2.0 X2

RS485

Support

General

Working Temperature

14 °F — 131 °F/-10 °C — 55 °C

Dimensions (W X H X D)

315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)

Weight (Without Hard Disk)

≤ 1.16 kg (2.6 lb)

Analog HD Camera

Image Sensor

8.29MP Sony STARVIS IMX274CMOSImage Sensor

Camera

Video Resolution

3840(H) X 2160(V)

Signal System

PAL/NTSC

Frame Rate

8MP@12.5 fps, 8MP@15 fps, 4MP@25 fps, 4MP@30 fps, 2MP@25 fps,
2MP@30 fps

Lens

2.8 mm

Min. Illumination

0.01 Lux@(F1.2, AGC On), 0 Lux with IR

Angle of View

102.2°

Number of Infrared LEDs

2

OSD Menu

Yes

Night Vision Distance

Up to 100 ft/30 m

DNR

2D DNR

Wide Dynamic Range

Digital WDR

IR-Cut Filter

Yes

Video Output

HD BNC X1

General

Housing

Plastic

Color

White

Operating Power

DC 12 V

Operating Temperature

-40 °F – 140 °F/-40 °C – 60 °C

Indoor/Outdoor

Indoor/Outdoor

Weatherproof Rating

IP67

Dimension (L X W X H)

58 mm X 61 mm X 159.8 mm (2.28" X 2.40" X 6.42")

Weight

0.46 lb./ 210 g
