Smar 4CH CCTV System 5MP 1080P 720P AHD Camera Kit 5 in 1 Video Recorder Surveillance System Outdoor Security Camera Email Alarm

$81.52$160.68

SKU: 2255800432684376 Categories: ,
  • Resolution: 5mp
  • PCS of Camera: 4PCS
  • Cable Length: None
  • Model Number: AK-W40-1/2/5-XDF
  • Brand Name: smar
  • Origin: Mainland China
  • Smart home platform: Other
  • Certification: NONE
  • Compression of DVR: H.264
  • Video Output: VGA,HDMI 1080P Output
  • P2P: Support (XMEYE)
  • Camera Resolution: 720P/1080P/5MP
  • Camera Shell: Plastic, Waterproof
  • Lens: Default 3.6mm lens
  • IR Leds: 6pcs Nano Infrared leds
  • Motion Detection: Support
  • Name: Surveillance Security Systems
  • Note: 720P/1080P/5MP AHD Kit Without Cable
  • APP: XMEYE
  • 720P AHD Kit: 4CH DVR 4PCS 720P Camera(No Cable)
  • 1080P AHD Kit: 4CH DVR 4PCS 1080P Camera(No Cable)
  • 5MP AHD Kit: 4CH DVR 4PCS 5MP Camera(No Cable)
  • 720P AHD Kit Cable: 4CH DVR 4PCS 720P 4PCS Cable
  • 1080P AHD Kit Cable: 4CH DVR 4PCS 1080P 4PCS Cable
  • 5MP AHD Kit Cable: 4CH DVR 4PCS 5MP 4PCS Cable

Feature::

1. The camera supports 720P,1080P/5MP HD resolution(Optional);

2. The kit supports Motion Detection and Email Alert;

3. Support H.264 video compression technology;

4.The camera has 6pcs Array IR LEDs, Day & Night Vision, 15-30m IR Distance.

5.Used Indoor or Outdoor, IP 66 waterproof.

6. The DVR is 4CH hybrid DVR, support AHD Camera, Analog Camera, IP Camera, TVI Camera, CVI Camera;

7. The DVR support 4CH BNC Video Input,1CH VGA+1CH HDMI Output; 1CH RCA Audio input and 1CH RCA Audio Output.

8. The DVR support 1PCS 3.5" SATA Hard Disk storage, max support 8TB.

9. The DVR Support 20+languages: It has English, Chinese, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Turkish, Polish,Romanian, Hungarian, Finnish, Farsi, Thai, Estonia, Vietnamese, Brazilian, Hebrew, Indonesian, Arabic, Swedish, Czech, Slovenia, Dutch…

10. The kit supports 7×24 hours loop recording, motion detection recording, and other recording modes, you can playback the recording to view;

11. Support web side, CMS, central management platform software XMEYE;

12.Supprt Cloud technology,Realize network penetration, front and rear end docking, and push alarm information to mobile phones.

Package List(1):

1 * 4CH Hybrid DVR

1 * Power Supply for DVR

1 * USB Mouse

1 * Fast Operation Guide

4 * 720P/1080P/5MP Waterproof AHD Cameras(Optional)

2 * Warning Sticker(gift)

***Hard Disk is not include in the kits***

(Note: For the PAL or NTSC .we will send it according to different countries.  )

Package List(2):

1 * 4CH Hybrid DVR

1 * Power Supply for DVR

1 * USB Mouse

1 * Fast Operation Guide

4 * 720P/1080P/5MP Waterproof AHD Cameras(Optional)

4 * 18M BNC Cable for Cameras

1 * DC12V Power adapter for Cameras

1 * 1 TO 4 Power Splitter for Cameras

2 * Warning Sticker(gift)

***Hard Disk is not include in the kits***

(Note: For the PAL or NTSC .we will send it according to different countries.  )

Experience with 720P & 1080P & 5MP HD System

Ideal for home or business -720P(1280 * 720) / 1080P(1920 * 1280) /5MP(2880*1616) offers exceptional Full HD resolution and quality enhancing efficiency and monitoring capabilities.

Smart IR-CUT Night Vision

The camera has a built-in mechanical IR-cut filter placed in front of the image sensor to filter out infrared light in the daytime, producing better color reproduction. At nighttime or when the built-in light sensor detects low-light conditions, the IR Cut Filter moves away from the lens to let in100% of the infrared light for maximum night vision performance. This results in the camera image changing to Black and White for better image quality.

Intelligent Motion Detection & Email Alert

You can enable motion detection alerts,When movement is detected in monitoring area, instant email will be sent to your mailbox and phone automatically. Get everything informed even you’re away from home.

VGA and HDMI Output

It supports VGA/HDMI output simultaneously. You only put the device to your TV or Desktop Computer to enjoy exceptional clear video.

Locate Incident Video With Smart Play

It effectively econnomized your time in playing back the video; Incident video clips can be found and marked in no time with smart playback function; so you get the chance to go directly to incident video clips while skipping others.



Easy access via multi-platform

Support Mobile Phone iOS, Android System,Remote view of mobile phones, any time… any where…

Mobile Remote access in seconds

Easy setting , just 4 steps for mobile phone viewing (Android and iPhone iOS)

Applied to Multiple Occasions:

Install and Connect it
It can be quickly and easily setup by anyone. Instantly see live video using your computer, tablet, or phone from anywhere.

4CH 1080N AHD DVR Specification for 720P  and 1080P Kit

Video compression: H.264

Encode capacity: 4x 1080N @25FPS, NTSC @30FPS

Video input/ output: 4CH BNC/ 1CH VGA, 1CH HDMI

Audio input/ output: 1CH RCA/ 1CH RCA

Recording , Playback , Backup resolution: 720P/1080N

USB: 2x USB 2.0

HDD: 1xSATA port (Max support up to 8TB)

Language: Support 10+languages,has English, Chinese, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Turkish, Thai,
Estonia, Vietnamese, Brazilian, Indonesian, Czech…

4CH 5M-N AHD DVR Specification for 5MP Kit

Video compression: H.264

Encode capacity: 4x 5M-N @25FPS, NTSC @30FPS

Video input/ output: 4CH BNC/ 1CH VGA, 1CH HDMI

Audio input/ output: 1CH RCA/ 1CH RCA

Recording , Playback , Backup resolution: 5M-N/1080P

USB: 2x USB 2.0

HDD: 1xSATA port (Max support up to 8TB)

Language: Support 20+languages: It has English, Chinese, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Turkish, Polish,

Romanian, Hungarian, Finnish, Farsi, Thai, Estonia, Vietnamese, Brazilian, Hebrew, Indonesian, Arabic, Swedish, Czech, Slovenia, Dutch…

Face Record/Face Detection/Face Playback

Record every face that appears on the lens, without missing any details.
You need use the Face Detction Function IP Camera

Your Camera Must support XM Face Detection, or will not work)

Only applicable to 5M-N(1080N don’t support)

AI Human Detection Alerts

Quickly finds human targets and immediately sends App notifications to your phone so you can see what’s happening anywhere.

Only applicable to 5M-N(1080N don’t support)

720P/1080P/5MP AHD Camera Specification

Effective Pixel:1280×720,1920×1080,2880*1616

Lens: Megapixel 3.6mm

Number of IR LEDs:6 pcs Array IR lEDs

Night Vision:20-30m IR Distance

IP66 Waterproof

IP66 professional security surveillance camera for Outdoor/Indoor use. Operating Conditions: -20 ~50 , Humidity 95% or less (non-condensing)

Product description and all-round display:
